Seasonic PSUSEA1300TR PRIME TX-1300 1300W Titanium Modular PSU

FEATURE SUMMARY

80 PLUS® Titanium certified

Micro Tolerance Load Regulation (0.5 %)

Cable-free Connection Design

Premium Hybrid Fan Control - Fanless until 40 % load

Multi-GPU setup

Gold plated connectors

Technical Specifications
80PLUS®
Titanium
Cybenetics Efficiency Level
TBA
Cybenetics Noise Level
TBA
Form Factor
Intel ATX 12 V
Dimensions
210 mm (L) x 150 mm (W) x 86 mm (H)
Fan Information
Fan Size
135 mm
Fan Control
Premium Hybrid Fan Control
Fan Bearing
Fluid Dynamic Bearing
Life Expectancy
50,000 hours at 40 °C, 15 % - 65 % RH
Cable Information
Modularity
Fully Modular
Cable type
Flat black cables
Electrical Features
Operating Temperature
0 - 50 °C
MTBF @ 25 °C, excl. fan
150,000 hours
AC Input
Full Range
Protection
OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental
Safety and EMC
cTUVus, TUV, CB, CCC, BSMI, EAC, CE
Environmental Compliance
Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty
12 Years
Power Output
AC Input
Voltage: 100 V - 240 V
Current: 15 - 8 A
Frequency: 50 Hz - 60 Hz
DC Output
Rail
+3.3 V
+5 V
+12 V
-12 V
+5 VSB
Maximum Power
25 A
25 A
108.3 A
0.5 A
3 A
125 W
1300 W
6 W
15 W
Total Continuous Power
1300 W
