Gigabyte GP-P650G PG5 GP-P650G PCIE 5.1, 650W, ATX12V v3.1, 80+Gold, 90%, 120mm HYB, PFC>0.9, 100-240V, 10-6A, 60-50Hz, MTBF>100k, PCIe5.1

Gigabyte GP-P650G PCIE 5.1, 650W, ATX12V v3.1, 80+Gold, 90%, 120mm HYB, PFC>0.9, 100-240V, 10-6A, 60-50Hz, MTBF>100k, OVP / OPP / SCP / UVP / OCP / OTP, PCIe5.1
Specification
Model
GP-P650G PG5​
Type
Intel Form Factor ATX 12V v3.1
PFC
Active PFC(>0.9 typical)
Input Voltage
100-240 Vac
Input Current
10-6A
Input Frequency
60-50 Hz
Output Capacity
650W
Dimensions
150 x 140 x 86 mm
Fan Type
120mm HYB Fan
80 PLUS
Gold
Efficiency
90% at typical load
MTBF
>100,000 hours
Protections
OVP / OPP / SCP / UVP / OCP / OTP
Power Good Signal
100-150ms
Hold Up Time
>17ms
Cable Type
Embossed, All black
Connectors
ATX / MB 20+4 Pin x 1 : 600mm*1
CPU / EPS 4+4 Pin x 1 : 600mm + 150mm*1
PCI-e 16 Pin x 1: 500mm*1
PCI-e 6+2 Pin x 2 : 500mm+150mm*1
SATA x 6 : 420mm+150mm+150mm*2
4 Pin Peripheral x 3 : 420mm+150mm+150mm*1
